TOTO NEOREST WX2 Wall-Hung Toilet

TOTO

SKU: CWT9548CEMFX#01

$25,957.00

Extra $9500 OFF Use FALL26 at checkout

Authorized TOTO National Dealer

Fast & Free Shipping On All Orders

Pay How You Want Credit Card, Shop Pay, PayPal, HSA/FSA with Truemed and more.

Hundreds of 5-Star Reviews Dedicated Customer Support

Questions? Talk to a Real Person.

(877) 420-3443 Message Us

TOTO NEOREST WX2 CWT9548CEMFX#01

The TOTO NEOREST WX2 combines the sleek, floating look of a wall-hung toilet with TOTO’s most advanced NEOREST cleaning and comfort technology.

Its standout feature is ACTILIGHT®, which uses UV light and a photocatalytic bowl surface to help break down microscopic organic residue between uses.

Combined with EWATER+®, PREMIST, CEFIONTECT® and TORNADO FLUSH®, it delivers TOTO’s most complete cleaning system in a wall-hung design.

The concealed in-wall tank keeps plumbing out of sight and allows the toilet to be mounted at a customized height.

The WX2 also includes automatic lid opening and flushing, continuous warm-water washing, a heated seat, warm-air dryer, deodorizer and personalized settings for up to four users.

ACTILIGHT® Self-Cleaning Technology

UV light activates the photocatalytic bowl surface to help break down microscopic organic waste between uses.

Sleek Wall-Hung Design

Creates a clean, floating look while keeping the floor underneath open and easy to clean.

Adjustable Installation Height

The concealed in-wall system allows installation from roughly 15" to 19" to suit the bathroom and user.

Cleans Before & After Every Use

PREMIST, EWATER+, CEFIONTECT and ACTILIGHT work together to help keep the bowl cleaner.

Fully Hands-Free

The lid opens and closes automatically, and the toilet flushes after use.

Unlimited Warm-Water Comfort

Enjoy continuous warm-water washing, a heated seat and warm-air dryer.

NEOREST WX2 Installation

TOTO NEOREST WX2 Compatibility

Plan the TOTO Neorest WX2 for the renovation phase when walls are open. This elongated, wall-hung smart toilet requires in-wall framing, carrier system, and electrical infrastructure.

Wall framing: Install 2x4 or 2x6 wall studs to support the carrier system and toilet weight during rough-in.
In-wall carrier system: TOTO in-wall tank and carrier bracket must be secured within the wall cavity before drywall closure.
Electrical outlet: GFCI 120V outlet within 3 feet of the toilet location powers the integrated smart bidet seat.
Drain configuration: Wall-mounted drain connection; coordinate with plumber before framing to set the correct height and angle.

Need a Professional Installer near you?

If you need help finding a professional installer in your area, checkout Licensed TOTO Installers page to find one near you.

TOTO NEOREST WX2 Downloads

TOTO NEOREST® WX2 Manual

TOTO NEOREST® WX2 Installation Manual

TOTO NEOREST® WX2 Spec Sheet

Frequently Asked Questions about NEOREST WX2

Which neorest feature is exclusive to the NX2 and WX2 models?

The exclusive feature found only on the NEOREST NX2 and WX2 models is ACTILIGHT® technology. This cleaning system uses light, oxygen, and water to help break down waste and keep the bowl cleaner automatically.

What is the difference between Neorest WX1 and WX2?

The main difference between the NEOREST WX1 and WX2 is that the WX2 includes ACTILIGHT® cleaning technology, while the WX1 does not. Aside from ACTILIGHT® and pricing, both models share nearly the same design, comfort, and advanced wash features.

Does the TOTO Neorest WX2 have a heated seat?

Yes. The TOTO NEOREST WX2 includes a heated seat with adjustable temperature control for added comfort.

Nothing Meets The Floor

A wall-hung NEOREST changes the room rather than the fixture. The WT175MA tank system carries everything inside the wall, so the floor runs unbroken underneath and a mop goes where it never could before.

The carrier adjusts through a 15 to 19 inch mounting height, which means the seat height is a decision your installer makes rather than one the box makes for you. TOTO rates the system to support up to 880 lbs.

What wall-hung actually buys you:

An unbroken floor line under the bowl
Mounting height adjustable from 15 to 19 inches
ADA compliant when the finished seat height lands between 17 and 19 inches
Rated to support up to 880 lbs

ACTILIGHT® Keeps Working On An Empty Room

ACTILIGHT is the one feature that separates the WX2 from the WX1, and it does its work on an empty room. Underneath it sits a photocatalytic glaze TOTO calls especially durable and hydrophilic.

Once the toilet lid is closed, the integrated UV light turns on for an hour. The UV light activates the photocatalyst and decomposes waste particles — a process TOTO calls natural, using no chemicals, just light, oxygen and water.

The cleaning you never see happen:

An hour of UV every time the lid closes
A photocatalytic glaze TOTO calls durable and hydrophilic
Less need for harsh detergents, in TOTO's own assessment
CEFIONTECT® glaze underneath, so less sticks to begin with

A Flush That Ignores Your Water Pressure

The WX2 flushes with HYBRID ECOLOGY SYSTEM, which TOTO describes as an advanced pressure-independent electric flushing system delivering exceptionally powerful, optimized performance. It is the same flush engine the WX1 carries.

Paired with ultra high-efficiency TORNADO FLUSH, TOTO states the combination provides powerful waste removal and enhanced bowl cleaning at 1.2/0.8 GPF. Auto flush handles it, and a back-up manual flush covers power outages.

Flushing, in numbers:

1.2 GPF / 0.8 GPF (4.5 / 3.0 LPF) dual flush
Electric flushing that TOTO calls pressure-independent
Auto flush with a back-up manual flush for power outages
2-1/4 inch trap diameter with a 2 inch trap seal

Warm Water, Warm Seat, Nothing To Touch

Washing is gentle aerated warm water, front and rear, with oscillating and pulsating features and independently adjustable spray position, temperature and pressure. The heater is instantaneous, so the warm water does not run out partway through.

The lid opens and closes touchlessly, the stick-style remote holds settings for four people, and a night light illuminates beneath the toilet and inside of the bowl. The seat is seamless, with no gap where dirt collects.

Living with the WX2:

Warm air dryer with five variable settings, up to 140ºF
Heated seat running 82ºF to 97ºF
Memory settings for up to four people
Automatic and programmable energy saving systems
Three Year Limited residential warranty

Comparing Neorest Models

All 7 models, side by side.

Standard on every Neorest

TORNADO FLUSH with CEFIONTECT
EWATER+ on wand, bowl, under seat
PREMIST before every use
Instant tankless water heating
Auto open and close lid
Auto flush with manual backup
Heated seat, warm air dryer, deodorizer
3-year residential warranty
4 saved user presets
Energy saver timer
ADA compliant
Night light

How does the NEOREST WX2 compare to the other Neorest models?

TOTO NEOREST models compared by price, installation, base, flush volume, seat height, actilight, remote, and finishes.
Features	RS	AS	LS	NX1	NX2	WX1	WX2 you're here
Price	$5,199	$6,783	$8,007	$11,452	$26,279	$10,897	$25,957
Model number	MS8341CUMFG	MS8551CUMFG	MS8732CUMFG	MS902CUMFG	MS903CUMFX	CWT9538CEMFG	CWT9548CEMFX
Installation	Floor mount	Floor mount	Floor mount	Floor mount	Floor mount	Wall hung	Wall hung
Base	Skirted, removable side panels	Skirted, removable side panels	Skirted, finish-matched side trim	Fully skirted ceramic	Fully skirted ceramic	In-wall tank	In-wall tank
Flush volume	1.0 / 0.8 GPF	1.0 / 0.8 GPF	1.0 / 0.8 GPF	1.0 / 0.8 GPF	1.0 / 0.8 GPF	1.2 / 0.8 GPF	1.2 / 0.8 GPF
Seat height	17-11/16 in.	17-1/4 in.	17-5/16 in.	17-5/16 in.	17-5/16 in.	Set at install	Set at install
ACTILIGHT	—	—	—	—	✓	—	✓
Remote	Block style	Stick style	Stick style, trim matched	Stick style	Stick style	Stick style	Stick style
Finishes	Cotton	Cotton	Cotton with silver, nickel or black trim, Matte Black, Matte White	Cotton	Cotton	Cotton, Matte Black, Matte White	Cotton

View all Neorest models (opens in a new window)

What do you get with the TOTO NEOREST WX2?

The TOTO NEOREST WX2 is sold as a complete wall-hung smart toilet system, including the bowl, integrated bidet top unit, concealed in-wall tank and nickel flush plate.

Because the tank and carrier are installed inside the wall, the WX2 requires more planning than a traditional floor-mounted toilet. The in-wall system should be positioned and installed before the wall is closed, with access to the required water supply and electrical connection.

Checkout all the Neorest WX2 features and specs below.

TOTO NEOREST WX2 Features

Feature	Details
Flushing and Bowl
Flush System	HYBRID ECOLOGY SYSTEM™ with TORNADO FLUSH®
Water Use	1.2 / 0.8 GPF (4.5 / 3.0 LPF)
Auto Flush	Auto flush, with back-up manual flush for power outages.
CEFIONTECT®	Ceramic glaze minimizes waste from sticking to porous ceramic surfaces.
ACTILIGHT®	CLEAN LIGHT technology built into the lid.
Bowl Design	Sleek, space-saving wall-hung design.
In-Wall Tank	WT175MA in-wall tank system (copper pipe)
Load Rating	Supports up to 880 lbs
Trap Diameter	2-1/4"
Trap Seal	2"
Water Surface	5-5/8" x 4-1/8"
Cleansing
Front and Rear Wash	Gentle aerated, warm water, front and rear spray.
Oscillating and Pulsating	Both spray features are listed on this sheet.
Adjustable Spray Position	Spray position is adjustable.
Adjustable Pressure	Water pressure is adjustable.
Adjustable Water Temperature	Water temperature is adjustable, Approx. 86ºF - 104ºF (30ºC - 40ºC).
Comfort
Instantaneous Water Heating	Instantaneous water heater, for continuous warm water and energy savings.
Heated Seat	Heated seat with temperature control, Approx. 82ºF - 97ºF (28ºC - 36ºC).
Warm-Air Dryer	Five variable temperature settings, Approx. 95ºF - 140ºF (35ºC - 60ºC).
Automatic Deodorizer	Automatic air deodorizer.
Universal Height	Universal Height, ADA compliant — ADA compliant when the seat height is between 17" and 19".
Cleaning and Hygiene
Photocatalytic Glaze	A photocatalytic layer on the bowl that TOTO describes as especially durable and hydrophilic.
UV Light in the Lid	Once the lid is closed the integrated UV light turns on for an hour, activating the photocatalyst.
EWATER+®	Auto-cleans the wand, bowl and under-seat after every use.
PREMIST®	Automatically mists the bowl before each use.
Self-Cleaning Wand	Cleans itself inside and out before and after every use.
CLEAN RESIN®	Keeps the wand and seat cleaner and easier to maintain.
Seamless Seat	Seamless seat design eliminates the gap where dirt collects.
Controls and Convenience
Remote Control	Multifunction ergonomic stick-style remote control.
User Memory	Personalized memory settings for up to 4 users.
Touchless Auto Open/Close Lid	Touchless auto open/close lid.
Night Light	Illuminates beneath the toilet and inside of the bowl.
Energy Saving	Automatic and programmable energy saving systems.

TOTO NEOREST WX2 Specifications

Specification	Details
Model	TOTO NEOREST WX2
Part Numbers	Set CWT9548CEMFX · bowl CT9548CEFX#01 · top unit SN9548MX#01 · in-wall tank WT175MA · push plate YT990#N (nickel)
Finishes	#01 Cotton
Installation	Wall-hung
Flush System	HYBRID ECOLOGY SYSTEM™ with TORNADO FLUSH®
Water Use	1.2 / 0.8 GPF (4.5 / 3.0 LPF)
In-Wall Tank	WT175MA in-wall tank system (copper pipe)
Mounting Height	15" - 19" adjustable mounting height (in-wall tank WT175MA)
ADA	ADA compliant when the seat height is between 17" and 19"
Load Rating	Supports up to 880 lbs
Water Surface	5-5/8" x 4-1/8"
Trap Diameter	2-1/4"
Trap Seal	2"
Water Supply Pressure	Min 7.25 PSI (dynamic) / max 108.75 PSI (static)
Power Rating	AC 120 V, 60 Hz
Power Consumption	1294 W (1452 W maximum)
Power Cord Length	1.6 ft (0.5 m)
Seat Temperature	Approx. 82ºF - 97ºF (28ºC - 36ºC)
Water Temperature	Approx. 86ºF - 104ºF (30ºC - 40ºC)
Dryer Temperature	Approx. 95ºF - 140ºF (35ºC - 60ºC)
Deodorizer	Automatic air deodorizer
Bowl Shipping Weight and Carton	88.4 lbs · 31-1/4" x 18-3/8" x 19-1/4"
Top Unit Shipping Weight and Carton	28.7 lbs · 31-1/4" x 20-5/8" x 9-7/8"
Warranty	Three Year Limited (Residential); One Year Limited (Commercial)
